China Electric Valve Actuator

China Electric Valve Actuator

China Electric Valve Actuator

1. Product Brief Introduction:

(1). Guarantee time: 1 year

(2). Top quality and good price
(3). Input signal: 4-20mA, 0-10VDC or 1-5VDC
(4). Adopted power: AC24V AC110V, 220V~240V, AC380~420V 50/60Hz
(5). Time: 9s/15s/20s/30s/60s
(6). Output torque: 150/250/300/500N. M
(7). Weight: 2.6kg
(8). Packing: Export carton

2. Product Spcification:

Model

JM 05

JM 10

JM 15

JM 25

JM 50

JM 100

JM 200

Power

AC24V,AC110V,AC220V,AC380V

Output torque

50N.M

100N.M

150N.M

250N.M

500N.M

1000N.M

2000N.M

Action time

12/25s

15/30s

50/100s

Motor power

15W

25W

30W

45W

90W

110W

110W

Rotory angle

0-90°

Temperature

-10-60°C

Withstand voltage

1500V

Starting current

0.25A

0.6A

0.68A

0.76A

1.2A

1.36A

1.36A

Working current

0.25A

0.52A

0.55A

0.70A

1.15A

1.28A

1.28A

IP code

IP67

Weight

2.8Kg

4.2Kg

4.5Kg

7.2Kg

7.5Kg

12.5Kg

12.5Kg

Input signal

4-20mA 1-10V 1-5V

Output signal

4-20mA 1-10V 1-5V


3. China Electric Valve Actuator Drawing Picture:

China Electric Valve Actuator Drawing

4. China Electric Valve Actuator Sample Picture:

China Electric Valve Actuator Sample
5. China Electric Valve Actuator With Valve Picture:

China Electric Valve Actuator With Valve
