Marine Cast Steel Flange Globe Valve
Marine Cast Steel Flanged Globe Valve:
1. Techinical data.
| NP(Mpa) | ND(mm) | Applicable medium |
| 1.0 | 65-300 | Fresh water ,lubricanling oil, fuel oil, t≤300℃ steam |
| 1.6 | 100-250 | |
| 2.5 | 20-150 | |
| 4.0 | 65-100 | Fresh water ,lubricanling oil, fuel oil, t≤400℃ steam |
| 6.4 | 20-50 |
2. Material
| Parts Name | Material | ||
| Name | Marks | ||
| Body,Cover | Cast steel | ZG230-450 | |
| Disc | High quality carbon steel | Steel 25 | |
| Stem | Stainless steel | 2Cr13 | |
| Disc seal ring | Weld stainless steel | H2Cr13 | |
| Body seal ring | PN≤2.5 | Weld stainless steel | H1Cr18N19T1 |
| PN≤4.0 | Weld stainless steel | H2Cr13 | |
3. Diagram drawing.
