Marine Vertical Centrifugal Pump (CLV):

CLV series vertical centrifugal pump is our newly developed product driven by a marine motor. It is widely used for transporting fresh water, seawater, condensate, oils and saline water. The transported medium shall not contain any abrasive materials and any other chemicals corrosive on the pump. It widely serves as fresh water and seawater cooling pump, bilge pump, ballast pump, fire fighting pump and general pump, and used for seawater desalting device and marine pressure cabinet. The transported medium temperature shall not exceed 80℃. AELC self-priming device can be assembled according to users’ order with additional cost, to achieve self-priming function. Viewed from the motor end downward, this series pump rotates clockwise.

performance parameters

ameters in case of power supply frequency of 50Hz 3φ 380V, please advise us if your required 60Hz 3φ 415V.
型号规格Type 主要参数(50Hz 3φ 380V) Main technical parameter 电机型号功率Motor type & powerkW 泵组重量WeightKg
流 量Capacitym3/h 扬 程Headm 转 速Speedr/min 汽蚀余量NPSHr m 轴 功 率Shaft power kW
CLV65-200A 27 14.5 1450 2.5 1.8 Y100L1-4H 2.2 170
CLV65-280A 30 21 1450 2.5 3.1 Y112M-4H 4 184
CLV65-300A 30 28 1450 2.5 4.4 Y132S-4H 5.5 215
CLV65-350A 25 41 1450 2.5 6.1 Y132M-4H 7.5 235
CLV80-200A 48 14.5 1450 2.5 2.8 Y112M-4H 4 186
CLV80-220A 45 62 2900 4 12 Y160M2-2H 15 370
CLV80-220B1 45 48 2900 4 9.8 Y160M1-2H 11 335
CLV80-280A 54 21.5 1450 3 4.5 Y132S-4H 5.5 215
CLV80-300A 46 28 1450 2.8 5.8 Y132M-4H 7.5 235
CLV80-350A 54 41 1450 3 10.5 Y160L-4H 15 422
CLV80-350B 40 35 1450 2.5 6.9 Y160M-4H 11 389
CLV80-350 B2 42 41 1450 2.5 8.4 Y160M-4H 11 389
CLV100-200 A 83 14.5 1450 3 4.6 Y132S-4H 5.5 215
CLV100-220 A 95 68.5 2900 4.5 24.2 Y200L1-2H 30 470
CLV100-220 B 87 55 2900 4.5 18.5 Y180M-2H 22 435
CLV100-280 A 83 21 1450 3 6.4 Y132M-4H 7.5 265
CLV100-300 A 83 28 1450 2.8 9.1 Y160M-4H 11 290
CLV100-350 A 83 41 1450 3.2 14.2 Y180M-4H 18.5 347
CLV125-200 A 116 14 1450 3.5 5.9 Y132M-4H 7.5 265
CLV125-220 A 149 68.5 2900 5.5 36.9 Y225M-2H 45 595
CLV125-220 B 128 55 2900 5 26.7 Y200L2-2H 37 510
CLV125-270 A 140 86 2900 5 44.7 Y250M-2H 55 800
CLV125-280 A 125 21 1450 3.5 9.6 Y160M-4H 11 300
CLV125-300A 125 28 1450 3 14.3 Y180M-4H 18.5 360
CLV125-350 A 125 41 1450 3.5 19.8 Y200L-4H 30 470
CLV125-350 B 116 34 1450 3.5 15.9 Y180L-4H 22 410
CLV150-200 A 190 14 1450 3.5 9.5 Y160M-4H 11 315
CLV150-220 A 273 62 2900 4.5 61.4 Y280S-2H 75 935
CLV150-270 A 265 86 2900 4 82.1 Y315S-2H 110 1280
CLV150-280 A 182 21 1450 3.5 13.4 Y180M-4H 18.5 390
CLV150-300 A 182 27.5 1450 4 17.7 Y180L-4H 22 430
CLV150-350 A 190 41 1450 3.5 29.1 Y225S-4H 37 550
CLV150-350 B2 190 35 1450 3.5 25.6 Y200L-4H 30 511
CLV200-200 A 332 13.7 1450 4 15.9 Y180M-4H 18.5 410
CLV200-280 A 330 20.5 1450 4.5 23.4 Y200L-4H 30 510
CLV200-280 B 290 17 1450 4.5 17.3 Y180L-4H 22 450
CLV200-280 B2 250 20.5 1450 4 17.9 Y180L-4H 22 450
CLV200-300 A 325 27.5 1450 4.5 30.3 Y225S-4H 37 571
CLV200-350 A 330 41 1450 4.5 46.5 Y250M-4H 55 820
CLV250-280 A 500 20.5 1450 4.5 34.8 Y225M-4H 45 895
CLV250-280 B 415 17 1450 4.2 24.4 Y200L-4H 30 800
CLV250-300 B2 415 27 1450 4.5 38.9 Y225M-4H 45 905
CLV250-350 A 500 34 1450 5 56.8 Y280S-4H 75 1150
CLV250-360 A 500 14 960 4 23.5 Y225M-6H 30 725
CLV250-360 B2 400 14 960 3.5 19.4 Y200L2-6H 22 675
CLV300-300 A 705 27.5 1450 4.5 64.7 Y280S-4H 75 1520
CLV300-360 A 660 14 960 4.5 31.8 Y250M-6H 37 800
CLV350-280 A 830 20.5 1450 4.8 57.6 Y280S-4H 75 1520
CLV350-280 B2 620 20.5 1450 4.5 44.1 Y250M-4H 55 1390
CLV350-360 A 829 14 960 3.8 39.4 Y280S-6H 45 1500
