LYB Vertical Arc Gear Pump

LYB Vertical Arc Gear Pump

LYB Vertical Arc Gear Pump:

Application
● Type: Vertical Installed Pump For Ship
● Characteristic: steady operating, low noise, long life and high efficiency.
● Temperature: The max environment temperature is 50℃. The max working environment temperature is 80℃.
● Axle Seal: This series of pump adopt mechanical sealing. It also adopts filling seal as requirement of customer.
Model Explanation
LYB 20 0.6
Vertical Circular Tooth Gear Pump Rated Flow m3/h Rated Pressure Mpa
Performance Parameters
Model Inlet / Outlet diameter (mm) Rated Capacity(m3/h) Rated Pressure
60Hz 50Hz Mpa
1180 rpm 900 rpm 970 rpm 720 rpm
LYB20 φ100/φ80 24 / 20 / 0.6
LYB25 30 / 25 /
LYB30 φ125/φ100 36 / 30 /
LYB40 φ150/φ125 48 / 40 /
LYB50 φ150/φ125 61 / 50 /
LYB65 / 65 / 55
LYB80 / 80 / 65
LYB90 / 90 / 75
LYB100 φ200/φ150 / 100 / 85
LYB150 / 150 / 125
LYB175 φ250/φ200 / 175 / 145
LYB200 / 200 / 165
