Rolling Rubber Fender
Rolling Rubber Fender
Specification:
1,fender can roll with fender remove, and generate a certain deformation.
2,Roller type fender mainly used in dock, water lock, different limitation water Chanel, and dock .Sticking out corner etc.
|
Specification |
Usually Maximum(mm) |
Usually Maximum Burthen (T) |
Energy Absorption (T-m) |
|
D1-060-20 |
125 |
7 |
0.25 |
|
D1-075-25 |
157 |
11 |
0.48 |
|
D1-090-30 |
184 |
15 |
0.88 |
|
D1-120-40 |
260 |
27 |
1.96 |
|
D1-150-50 |
325 |
43 |
3.84 |
|
D1-180-60 |
390 |
62 |
6.63 |
|
D1-210-70 |
455 |
84 |
10.7 |
|
D1-240-80 |
520 |
110 |
15.7 |
|
D2-060-20 |
125 |
14 |
0.5 |
|
D2-075-25 |
157 |
21 |
1.0 |
|
D2-090-30 |
184 |
31 |
1.7 |
|
D2-120-40 |
260 |
55 |
3.9 |
|
D2-150-50 |
325 |
86 |
7.7 |
|
D2-180-60 |
390 |
124 |
13.3 |
|
D2-210-70 |
455 |
169 |
21.0 |
|
D2-240-80 |
520 |
220 |
32.0 |
|
D3-060-20 |
125 |
21 |
0.7 |
|
D3-075-25 |
157 |
32 |
1.4 |
|
D3-090-30 |
184 |
46 |
2.5 |
|
D3-120-40 |
260 |
82 |
6.0 |
|
D3-150-50 |
325 |
128 |
11.0 |
|
D3-180-60 |
390 |
185 |
20.0 |
|
D3-210-70 |
455 |
252 |
32.0 |
|
D3-240-80 |
520 |
329 |
47.0 |
