Gear Pump

We are the china's most trusted provider for Gear Pump. You Can Buy Various High Quality Gear Pump products from Hi-Sea Group.

A gear pump uses the meshing of gears to pump fluid by displacement.They are one of the most common types of pumps for hydraulic fluid power applications.
Gear pumps are also widely used in chemical installations to pump high viscosity fluids. There are two main variations; external gear pumps which use two external spur gears, and internal gear pumps which use an external and an internal spur gear. Gear pumps are positive displacement or fixed displacement, meaning they pump a constant amount of fluid for each revolution. Some gear pumps are designed to function as either a motor or a pump.

Theory of operation:
As the gears rotate they separate on the intake side of the pump, creating a void and suction which is filled by fluid. The fluid is carried by the gears to the discharge side of the pump, where the meshing of the gears displaces the fluid. The mechanical clearances are small— in the order of 10 μm. The tight clearances, along with the speed of rotation, effectively prevent the fluid from leaking backwards.
The rigid design of the gears and houses allow for very high pressures and the ability to pump highly viscous fluids.
Many variations exist, including; helical and herringbone gear sets (instead of spur gears), lobe shaped rotors similar to Roots blowers (commonly used as superchargers), and mechanical designs that allow the stacking of pumps.


Generally used in:

Petrochemicals: Pure or filled bitumen, pitch, diesel oil, crude oil, lube oil etc.

Chemicals: Sodium silicate, acids, plastics, mixed chemicals, isocyanates etc.
Paint and ink.
Resins and adhesives.

Pulp and paper: acid, soap, lye, black liquor, kaolin, lime, latex, sludge etc.

Food: Chocolate, cacao butter, fillers, sugar, vegetable fats and oils, molasses, animal food etc.
